ATEK1001 is a pre-selector module covering 485 – 8000 MHz frequency band. Pre-selector consists of an SP8T switch followed by 7 fixed frequency sub-octave band pass filters which are followed by another SP8T switch. 8th path is a bypass path which provides user to bypass the filters.
RF Input and Outputs are internally matched to 50 ohms for ease of use.
Pre-selector provides 43 dBm IIP3 which allows users to realize high dynamic range wideband receiver frontends. Sub-octave filterbank architecture improves overall system IIP2.
Pre-selector is housed in custom milled metal enclosure with USB interface which allows simple control and the bias supply.
Custom package and module options are available upon request.
| Parameter | Min | Typ | Max | Units | ||
|---|---|---|---|---|---|---|
| Frequency Range | 2 | 8000 | MHz | |||
| 3dB Bandwidth
(High Pass 3dB cutoff – |
Band 1 | 485 – 810 | MHz | |||
| Band 2 | 670 – 1125 | |||||
| Band 3 | 960 – 1670 | |||||
| Band 4 | 1440 – 2560 | |||||
| Band 5 | 2140 – 3850 | |||||
| Band 6 | 3300 – 5880 | |||||
| Band 7 | 4820 – 8500 | |||||
| External Bypass | 2-8000 | |||||
| Insertion Loss | Filter Paths | 6.5 | dB | |||
| External Bypass Path | 3.5 | |||||
| Input IP3 | 43 | dBm | ||||
| Switching Speed | 150 | nS | ||||
| DC Supply Current over USB | 20 | mA | ||||
| Operating Temperature | -40 | 85 | °C | |||
