ATEK846N4
18 GHz Low Pass Filter
Product Features
- Frequency Range: LF – 18 GHz
- Insertion Loss: 2.7 dB
- 4×4 mm compact size
Applications
- Wideband Receivers
- Telecommunication
- Test and Measurement
- SATCOM
- SDR
Product Description
ATEK846N4 is a low pass filter with low in band loss and high rejection. Filter developed in highly repeatable MMIC manufacturing process, which results in minimal part to part variation.
Filter housed in compact 4×4 mm low cost SMD package, input and output are matched to 50 ohms internally.
Evaluation Board, bare die, custom package, and module options are available upon request.
| Parameter | Min | Typ | Max | Units | ||
| Operational Frequency Range | LF – 18 | GHz | ||||
| Insertion Loss | 9 GHz | 0.9 | dB | |||
| 18 GHz | 2.7 | |||||
| Rejection | 21.3 GHz | 40 | dBc | |||
| 28 GHz | 40 | |||||
| Input Return Loss | -19 | dB | ||||
| Output Return Loss | -19 | dB | ||||
| Operating Temperature | -40 | 85 | °C | |||
